Application

● Replacement of metal oxide film resistor
● Able to downsize mounting boards
● High voltage circuit (such as LED)

Features

● Very small and high-power rating
(1 rank smaller than miniature size)
● Resistant to high voltage
● Possible to make precision tolerance(0.5％)
● Coating is flame retardant grade “UL94 V-0”
● RoHS, REACH compliant
